Product Description
Shentuo ST series trucks are mainly used in underground non-coal mines, mainly for transporting mine materials after blasting, but also for roads, railroads and other narrow, low, harsh environment of the tunnel project. The core parts of this series of trucks are all international famous brand products, with compact structure design, strong power and stable performance. It is comfortable to drive and efficient in transportation.
The ST20 truck is an underground mining truck with a carrying capacity of 20 tons.The truck is built to offer the flexible mobility necessary in narrow-vein mining conditions. Equipped with a European Stage III A engine to provide users with cleaner and more efficient vehicle operation. Product Parameters
| | Item | Unit | ST20 Underground Mining Truck |
| Capacity | Standard Bucket | m³ | 10 |
| Operating Weights | kg | 22800 |
| Tramming Capacity | kg | 20000 |
| Breakout Force | kN | 252 |
| Discharging Time | s | 11 |
| Configuration | Drive Model | | 4×4 |
| Transmission Model | | Hydromechanical |
| Brake Model | Working Brake | | Spring Applied And Hydraulic Released Equipment |
| Parking Brake | | Spring Applied And Hydraulic Released Equipment |
| Equipment Size | Dimension | mm | L | 9150 |
| W | 2250 |
| H | 2450 |
| Ground Clearance | mm | 350 |
| Wheelbase | mm | 4450 |
| Turning Radius | mm | Inner | 4120 |
| | Outer | 7530 |
| Dump Position Height Max | mm | 4630 |
| Performance | Speed | km/h | 1st Gear | 6 |
| 2nd Gear | 10 |
| 3rd Gear | 14.5 |
| 4th Gear | 26 |
| Gradeability | % | 25 |
| Diesel Engine | | | Volvo TAD853VE |
| Power | kW | 235 |
| Torque | Nm | 1300 |
| Engine Speed | rpm | 2200 |
| Displacement | L | 7.7 |
| Fuel Injection System Form | | Common Rail |
| Emissions | | Tier 3, Euro Stage III A,CN 3 |
| Fuel Tank Refill Capacity | L | 380 |
| Transmission system | Converter | | Dana CL5000 |
| Transmission | | Dana R36000 |
| Axle | | Dana 20D |
| Tire | | 18.00-25 |
| Optional | Automatic Central Lubrication | | Lincoln |
| Centralized Fire Extinguishing System | | Ansul |
| Emissions | | Euro Stage Iv |
Company Profile
Hubei Shentuo Intelligence Equipment Co., Ltd. is a wholly-owned subsidiary of Yimu Intelligence Technology Co., Ltd. and consists of Hubei Suizhou production plant and Wuhan R&D center, which is a technology-based enterprise focusing on the research and development, production, sales, after-sales and export of underground equipment for coal and metal mines, aiming at the global market with its products.
Shentuo Intelligence is based on scientific and technological innovation and oriented to customers' needs. Currently, Shentuo Intelligence has a new generation of concrete mixer trucks, loaders, mine trucks and other series of diesel and purely electric models, which can adapt to customers' mining needs in a variety of situations, improve the productivity and economic benefits of mining, and strive to improve the sense of safety and happiness of underground workers.
Shentuo Intelligence adopts advanced quality management system to provide first-class quality underground equipment: at the same time, Shentuo Intelligence adheres to intelligent manufacturing, and builds up the leading manufacturing capacity of underground equipment industry through advanced ERP and informationization system to ensure the delivery cycle. In the future, Shentuo Intelligence will continue to be committed to all-round innovation, provide the most intelligent and efficient technology and products for the domestic and international mining industry, and make continuous efforts to promote productivity enhancement, industry development and ESG construction!
Exhibition
Certifications
Packaging & Shipping
Our Advantages
FAQ
1. Q: What kind of terms of payment can be accepted?
A: Normally we can work on T/T and other terms is also negotiable.
2. Q: Which incoterms 2010 terms can we work?
A: Normally we work on FOB, CFR, CIF, EXW.
3. Q: What about the delivery time?
A:It depends on the model, usually 2-6 months after receiving the deposit.
4. Q: What about the warranty time?
A: In12 months after shipment, o within 2000 hours of equipment operation, we can provide the free repair service.
5. Q: What about the Minimum Order Quantity?
A: The MOQ is 1 set.
6. Q: Could you stick customers' brands on the products?
A: We warmly welcome the OEM orders.
